Air Spraying Six Axis Coating Robot Painting Machine 1.5m Integrated
Hot sell and factory price six axis coating robot with spray painting robot
| Structure | Robotic Arm CNC | Acceptance torque | J4 axis 4.45N.m |
| Loading | 10KG | J5 axis 4.45N.m | |
| Repeated positioning accuracy | ±0.06mm | J6 axis 2.2N.m | |
| Action range | J1 axis(rotation)-175°~+175° | Acceptance inertia moment | J4 axis 0.27kg.m2 |
| (arm-hanging-60°~+60°) | J5 axis 0.27kgs.m2 | ||
| J2 axis(lower arm)-142°~+64° | J6 axis 0.03kgs.m2 | ||
| J3 axis(upper arm)-81°~+170° | The maximum length of arm | 2022MM | |
| J4 axis(arm rotation)-178°~+178° | The weight of the body | 221kg | |
| J5 axis(wrist swing)-132°~+132° | Installation environment | Temperature 0~+400 | |
| J6 axis(wrist rotation)-720°~+720° | Humidity 20-80%RH | ||
| The maximum speed | J1 axis(rotation)170°/s | Vibration 4.9m/s2 | |
| J2 axis(below arm)165°/s | Others: keep away from the electrical noise source | ||
| J3 axis(upper arm)170°/s | Capacitance | 1.5kVA | |
| J4 axis(arm rotation)360°/s | Installation method | Floor and arm hanging | |
| J5 axis(wrist swing)360°/s | |||
| J6 axis(wrist rotation)360°/s |
Why use our Helmet automatic spraying robot?
How about after sale serivce?
1. Provide technical support and production line upgrade
2. Feedback withini 12 hour after receive fault notification or service requirement
3. Free training
4. User-friendly English manual or operation video for machine using and maintanence.
6. On time delivery.
